Quick Specs

  • Size:2-1/16" (52.4mm)
  • Type:Air-Core
  • Range:0 Ω Empty / 30 Ω Full
  • Lighting:Incandescent
  • Instructions: Download PDF


One of the most necessary gauges in a dashboard, AutoMeter makes it easy by offering a variety of different fuel level gauges to match the resistance range of your existing fuel sending unit. Our patented air core meter movement receives extra dampening to help combat the effects fuel slosh in non-baffled tanks. Don’t get stranded down the road or at the track.

Feature Points
  • Traditional incandescent lighting illuminates around the perimeter of the dial
  • Works with most Pre-1965 Chevrolet/GM senders
  • 12 and 16 volt compatible, well-suited with nearly every street car or race car electrical system
  • Gauge kit includes bulb and socket assembly, red and green bulb covers, mounting hardware, and detailed instructions for installation
  • AutoMeter's race proven air-core electric instruments provide quick and accurate readings
  • Domed Lens
Ships With
  • 2230
California Residents: Prop 65 WARNING prop65 Cancer, Birth Defects and Reproductive Harm


  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getReviews, 48.28ms
  • bvseo-msg: HTTP status code of 404 was returned;


Can this be used on a 6 volt + ground system. Maybe with a resistor?

Asked by: Calvin
This will require a negative ground system, as it will not work on a positive ground.
Answered by: Thomas From AutoMeter
Date published: 2022-11-03

What is the overall depth of the gauge.

Asked by: ccraig
Thank you for your question The depth is 1-1/2".
Answered by: Natalia from AutoMeter
Date published: 2021-01-18

I installed all arctic white guages inmy 1953 chevy restore.All guages worked for1250 miles I was impress with function and looks Fuel guage showed 1/2 tank of gas 20 miles later I ran out of gas. Guage showed 1/2. What can I do to trouble shoot?

Asked by: Dutch
Hello! This will likely require some back and forth dialogue with our Tech Support Team, so we’d recommend sending us a detailed email here:
Answered by: Natalia from AutoMeter
Date published: 2020-11-16

I have an Autometer Fuel Gauge that only always reads far right, with power on or off. It used to float as I stopped and started. It’s about 20 years old. initially purchased in a cluster of Billet instruments for a 56 Chevy Truck. Repair or Replace?

Asked by: Dexter
If you would like you can send the unit into us for evaluation. Please use the form linked:
Answered by: Steve from AutoMeter
Date published: 2020-06-03

which artic white fuel gauge is able to be calibrated

Asked by: vetteman85
Thank you for your inquiry. We do not offer a programmable fuel level gauge in the Arctic White line. We do offer a number of Arctic White fuel level gauges for the most common sending unit ranges. If you don't see one that fits your application on our website, call our Tech Line at 866-248-6357 for other options.
Answered by: Jim from AutoMeter
Date published: 2019-01-21

I am wanting to use this fuel gauge in a 2001 Jeep Cherokee sport. Can I get it in the proper resistance.

Asked by: Stretch
Thank you for your question. We do not have any confirmation of the ohm range on the 2001 Jeep Cherokee Sport. I recommend you contact our tech team so they can walk through the steps of determining which gauge it is you will need. You can contact them by calling 866.248.6357 or submitting a contact form here:
Answered by: Zach from AutoMeter
Date published: 2019-11-19

do you sell just sender for this gauge

Asked by: vetteman85
Thank you for your question. Unfortunately, we do not. We only sell one fuel level sender and it is our #3262 and it is 240-33Ohm sending unit.
Answered by: Zach from AutoMeter
Date published: 2020-01-27

Hello, would this gauge fit my 1993 Honda Civic hatchback? If not what gauge would you recommend?

Asked by: Ali80
Thank you for your question. We do not make gauges to fit specific vehicles, our gauges are made to fit a specific sized hole. Our gauges fit 2-1/16" or 2-5/8" holes. As far as compatibility with your vehicle. I would recommend part #5710. It is a programmable fuel level gauge which can be set to work with the fuel level sender in your civic. For further questions or specific instructions for your application, please contact our support team here:
Answered by: Zach from AutoMeter
Date published: 2018-09-28
