2-5/8" VACUUM/BOOST, 30 IN HG/20 PSI, MECHANICAL, MARINE CHROME

2-5/8" VACUUM/BOOST, 30 IN HG/20 PSI, MECHANICAL, MARINE CHROME

Product # 200775-35
$74.95

OR
  • 2-5/8" (66.7mm)
  • Mechanical Mechanical
  • 30 IN HG/20 PSI
  • Incandescent
  • Download
  • Ships in 5 Business Days
  • Free Shipping Over $99*
  • Hassle Free Returns
SHARE
Description
The standard in the industry, AutoMeter’s Mechanical Boost/Vac gauges have found their way into more builds than any other. Using a patented, high precision bourdon tube meter movement, there isn’t another gauge on the market that can lay claim to the levels of accuracy or durability you’ll find here. A simple 1/8” NPT pressure connection requires no electrical hookup for operation. Appropriate 1/8” NPT fittings and line kits are available separately.
ADDITIONAL NOTES

Feature Points

  • Features front sealed bezel design for added water resistance and UV protected paint on dial pointer for added protection against sun damage
  • Requires AutoMeter 3223 nylon tubing kit (10 ft.) to connect from gauge to pressure source (sold separately) - Marine parts distributors may also offer their own tubing solutions
  • Gauge kit includes bulb and socket assembly, red and green bulb covers, corrosion resistant mounting hardware, and detailed instructions for installation
  • 12 month limited warranty
  • Traditional incandescent lighting illuminates around the perimeter of the dial
SHIPPED WITH

Bulb & Socket

  • 3220

Light Covers

  • Red 3214 & Green 3215

Mounting Hardware

  • 2226
Reviews
  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getContent, 162.95ms
  • REVIEWS, PRODUCT
  • bvseo-msg: HTTP status code of 404 was returned;
Questions

What is overall diameter of this gauge? Not the face, but the diameter of the chrome ring around the face? Thanks.

Asked by: Biminiblue
Thank you for the question. Generally we refer to the outer diameter of the 2-5/8" gauge bezel as 2-13/16." A more specific measurement on the chrome bezel, which adds more material to the thickness of the bezel, is closer to 2.83 inches.
Answered by: Matt from AutoMeter
Date published: 2018-01-08
