In stock


Shipping in 2-4 business days
Free Shipping over $99
Hassle Free Returns

Quick Specs

  • Size:2-1/16" (52.4mm)
  • Type:Air-Core
  • Range:100-250 °F
  • Lighting:Incandescent
  • Instructions: Download PDF


A high water temp can be detrimental to an engine. Heat is the enemy of performance and reliability. Keep tabs on your temps with the most trusted water temperature gauge on the market. AutoMeter’s advanced 1/8” NPT temperature transducer is included for a simple installation on any application.

Feature Points
  • Traditional incandescent lighting illuminates around the perimeter of the dial
  • 12 and 16 volt compatible, well-suited with nearly every street car or race car electrical system
  • Gauge kit includes 1/8” NPT temperature sender, 3/8” and 1/2" NPT adapters, bulb and socket assembly, red and green bulb covers, mounting hardware, and detailed instructions for installation
  • AutoMeter’s race proven air-core electric instruments provide quick and accurate readings while keeping hazardous fluids outside of the vehicle
  • Domed Lens
Ships With
  • 2258
  • 3/8" NPT and 1/2" NPT adapter fittings
  • 2230
California Residents: Prop 65 WARNING prop65 Cancer, Birth Defects and Reproductive Harm



  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getReviews, 65.53ms
  • bvseo-msg: HTTP status code of 404 was returned;


I am replacing a 2 1/16 water temp gauge, Antique Beige with a black trim ring. Can I still order one with the black ring? I don't see them advertised anywhere

Asked by: blackbart
Unfortunately this gauge is only available as shown with the chrome bezel.
Answered by: Jim from AutoMeter
Date published: 2022-09-12

Some of Antique Beige series gauges seem to have a different shade of beige. Is this just how it looks on the screen, or are they actually different shades?

Asked by: Hammer808
They are all the same color. The lighting may be off when taking photos for our website.
Answered by: Steve from AutoMeter
Date published: 2022-07-14

Can gauge 1837 be had with a 1/2 NPT sender instead of the 3/8 sender included. Would like to mount without using a bushing if possible. Thanks

Asked by: Buzz56
The only two senders that would work for this gauge are the 2258 and the 2259.
Answered by: Thomas From AutoMeter
Date published: 2022-04-26

How do I order the brass/gold trim ring instead of the chrome one?

Asked by: Ucsoricksh
If you could, reach out to our Customer Service team for more information.
Answered by: Thomas From AutoMeter
Date published: 2022-04-14

Will this gauge work with my 1959 Jeep CJ5 F-134 engine? Also will the sending unit fit in the gas tank hole?

Asked by: nanneyman
Yes, this gauge will include an 1/8” NPT sender along with a 3/8” and ½” NPT adapter. Your 1959 Willys will be compatible with one of these.
Answered by: Sarah from AutoMeter
Date published: 2021-10-04

I have an older water temp gauge that looks like your product # 1837(chrome trim ring). The gauge I have has a god trim ring. I think the product # I have is 1538. What would be the product # for the 1538 water temp gauge?

Asked by: John De
Thank you for your question. They actually share the same part number P/N: 2258.
Answered by: Steve from AutoMeter
Date published: 2020-02-07

I've got these gauges, antique beige, for water, oil, tack, and rpm. I'd like to add a trans temp gauge but autometer doesn't offer one in antique beige. Will this water temp gauge work as a trans temp gauge. Fittings are alike & range is the same.

Asked by: Gusteve
Thank you for your inquiry. You can certainly monitor transmission temperature with a water temp gauge. They are identical except for the dial markings.
Answered by: Jim from AutoMeter
Date published: 2019-05-28

What sender unit do I need for this gauge? Does it come with the gauge? If not supplied could you point me to the exact sender unit on your website so I can buy one. I need to know the thread size as I need to tap my radiator to make it fit.

Asked by: Geof
Thank you for your question. This gauge will come with our #2258 sending unit which has an 1/8" NPT thread.
Answered by: Zach from AutoMeter
Date published: 2019-05-10
