Professional Motorsports Data Logger

Professional Motorsports Data Logger

Product # ST269501

  • MFR (Multi-Function Recorder)
  • Ships in 2 Business Days
  • Free Shipping Over $99*
  • Hassle Free Returns

Due to the complexity of this product, this product ships in 4 weeks from the date of purchase.

15 Input Bracket System (Incl: Display, sensor & network harness, Driveshaft RPM Sensor Kit, USB DataDrive, Logging (14 channels, 200Hz sample rate, 2MB), DataPro Drag software & user manual). Not compatible with Standard DataPro Analysis Software, ECU data, GPS NMEA data.


Total Recording Channels

  • 14

Sensor Inputs

  • 10

Feature Points

  • Includes ST918024-101 ECU ES Extender, ST269512 Driveshaft RPM Kit, ST269526 6ft Cable Extender, ST269528 Drag Logger Harness, ST269620 DataDrive, and DataPro Software.
  • Adjustable Sample Rate Per Channel = 1-200Hz
  • Highspeed Download True CAN-USB Device, with remote access port. Direct access to logger not required for download allowing greater mounting flexibility.
  • Multiple Run Recording and Storage. Passes time and date stamped when recorded, so you know which run occurred when even if you can't download immediately after a pass.
  • Water, Dust/Dirt, Shock, and Vibration Proof! Fully sealed to IP67 standard. Ensures that your data will be captured and stored no matter what.
  • Compatible with Ultra-Lite Pro & Pro Comp Pro Series Gauges. Run your data logger & instruments without compromise. Simplify wiring with plug & play installation. Set custom warnings for instant driver alert and reivew peaks with one touch recall.
  • Tri-Axis Accelerometer +/-6g
  • Battery Voltage Channel
  • Add Up To 10 More Recording & Sensor Input Channels with Expansion Module #9610.
  • Windows XP, Vista, and 7 (32 & 64 bit operating systems) Compatible DataPro Analysis Software

Sending Units

  • Includes Driveshaft Sensor and Collar

Wire Harness

  • Yes

Harness Length

  • 10ft
